Features:high efficient transmission,low noise,              withstand oil and strain,without elasticity,              no extension,high torque,withstand abrasion,              working temperature range from -30℃ to 80℃.
This product is widely applied to security, glass ceramic, wood, metal plastic,printing, packaging, textile, food, tobacco, instrumentation, communication cable, electrical  appliance,car,sports and other industries of mechanical transmission.
Arc Tooth Timing Belt-STD2MM
Pitch=2mm
Specification	Number of tooth	Section line length (mm)		Specification	Number of tooth	Section line length (mm)
S2M-90	45	90		S2M-320	160	320
S2M-112	56	112		S2M-324	162	324
S2M-114	57	114		S2M-328	164	328
S2M-116	58	116		S2M-334	167	334
S2M-128	64	128		S2M-336	168	336
S2M-130	65	130		S2M-338	169	338
S2M-132	66	132		S2M-340	170	340
S2M-134	67	134		S2M-354	177	354
S2M-140	70	140		S2M-360	180	360
S2M-142	71	142		S2M-370	185	370
S2M-144	72	144		S2M-400	200	400
S2M-150	75	150		S2M-406	203	406
S2M-152	76	152		S2M-420	210	420
S2M-156	78	156		S2M-426	213	426
S2M-158	79	158		S2M-430	215	430
S2M-160	80	160		S2M-436	218	436
S2M-172	86	172		S2M-452	226	452
S2M-174	87	174		S2M-460	230	460
S2M-176	88	176		S2M-468	234	468
S2M-180	90	180		S2M-474	237	474
S2M-182	91	182		S2M-494	247	494
S2M-186	93	186		S2M-500	250	500
S2M-188	94	188		S2M-506	253	506
S2M-190	95	190		S2M-520	260	520
S2M-192	96	192		S2M-530	265	530
S2M-198	99	198		S2M-556	278	556
S2M-200	100	200		S2M-560	280	560
S2M-204	102	204		S2M-572	286	572
S2M-208	104	208		S2M-600	300	600
S2M-210	105	210		S2M-604	302	604
S2M-212	106	212		S2M-630	315	630
S2M-214	107	214		S2M-648	324	648
S2M-218	109	218		S2M-656	328	656
S2M-224	112	224		S2M-660	330	660
S2M-230	115	230		S2M-710	355	710
S2M-234	117	234		S2M-726	363	726
S2M-236	118	236		S2M-760	380	760
S2M-240	120	240		S2M-800	400	800
S2M-252	126	252		S2M-856	428	856
S2M-260	130	260		S2M-860	430	860
S2M-262	131	262		S2M-880	440	880
S2M-264	132	264		S2M-892	446	892
S2M-266	133	266		S2M-940	470	940
S2M-274	137	274		S2M-976	488	976
S2M-290	145	290		S2M-984	492	984
S2M-300	150	300		S2M-1166	583	1166
S2M-306	153	306		S2M-1224	612	1224
S2M-308	154	308		S2M-1250	625	1250
S2M-314	157	314		S2M-3000	1500	3000
Specification and size are unfinished,welcome to contact us for more information!
