Mechanism Properties: Stable dimension, low preliminary tension, low noise High resistance to wear,free from maintain Highest linear speed can be 80m/s Chemical Properties: Anti-aging, waterproof solution, UVA resisitence,ozone resisitence Working temperature:-30℃～+80℃, can withstand 110 degrees within short time Resisit most oil & grease This type of product is commonly used in the transmission of control industry such as machine tool, textile and print,electrical cable,instrument,oil chemistry,tobacco,communicative equipment.
Trapezoidal Tooth Timing Belt -T2.5
Pitch=2.50mm
Specification	Number of tooth	Section line length (mm)		Specification	Number of tooth	Section line length (mm)
T2.5-82.5	33	82.50		T2.5-380	152	380.00
T2.5-120	48	120.00		T2.5-395	158	395.00
T2.5-145	58	145.00		T2.5-400	160	400.00
T2.5-160	64	160.00		T2.5-420	168	420.00
T2.5-177.5	71	177.50		T2.5-457.5	183	457.50
T2.5-182.5	73	182.50		T2.5-480	192	480.00
T2.5-185	74	185.00		T2.5-492.5	197	492.50
T2.5-190	76	190.00		T2.5-500	200	500.00
T2.5-200	80	200.00		T2.5-540	216	540.00
T2.5-225	90	225.00		T2.5-600	240	600.00
T2.5-230	92	230.00		T2.5-620	248	620.00
T2.5-240	96	240.00		T2.5-635	254	635.00
T2.5-245	98	245.00		T2.5-650	260	650.00
T2.5-252.5	101	252.50		T2.5-680	272	680.00
T2.5-265	106	265.00		T2.5-700	280	700.00
T2.5-280	112	280.00		T2.5-780	312	780.00
T2.5-285	114	285.00		T2.5-825	330	825.00
T2.5-290	116	290.00		T2.5-880	352	880.00
T2.5-305	122	305.00		T2.5-915	366	915.00
T2.5-317.5	127	317.50		T2.5-950	380	950.00
T2.5-330	132	330.00		T2.5-1185	474	1185.00
T2.5-335	134	335.00		T2.5-1300	520	1300.00
T2.5-342.5	137	342.50		T2.5-1750	700	1750.00
Specification and size are unfinished,welcome to contact us for more information!
